Paul's Clubhouse Plan・2-Options

Double the choices, double the fun! The Paul’s Clubhouse Play Set Plan comes in two exciting versions to suit your space and imagination. The standard plan features a classic two-level clubhouse, perfect for young adventurers to climb, explore, and call their own. For families looking to go all out, the deluxe version adds a third level for even bigger adventures and sky-high views. Both designs are packed with charm and provide plenty of room for creativity, from pretend missions to backyard hideouts.

No matter which version you choose, these clubhouses are built with fun in mind. The open layout and sturdy platforms make it easy to add playground accessories like slides, ladders, climbing walls, or rope bridges. With plenty of space to play, decorate, and personalize, Paul’s Clubhouse is a fantastic DIY project that becomes a lasting centerpiece of outdoor fun. Whether it’s a secret spy HQ or a cozy treetop getaway, this design is a backyard favorite in the making.

Features:

• Choose two different designs, with one having a 3rd level loft (Deluxe) and the other having a traditional lean-to roof (Standard)

• 80ft² (Standard) or  in usable play space
• Includes instructions to build a rock wall & ship ladder
• Trap door to the 3rd level (Deluxe)

• Room for ship ladder, slide and rock wall
• 5.5' Max interior head room
• Bottom can be used as a sand box
• Fire pole exit from the top level
• 8 window openings
• Designed for children aged 3-10
• 32 page, step by step PDF plan

Plan Category:

🤸🏼 Playground Playset Plans

Dimensions:

• 8' Wide
• 10' Deep
• 14' Tall

Framing Details:

• Joists: 2x6 - 16" O.C.
• Walls: 2x4 - 16" O.C.

Windows:

• (8) 18" x 27" single pane, shed windows

Lumber List | Deluxe:

Make sure to take advantage of any volume discount from your local lumber yard!

Decking:
( 55 ) 5/4” x 6” x 8'
( 15 ) 5/4” x 6” x 10'
( 2 ) 5/4” x 6” x 12'

2x4:
( 36 ) 2” x 4” x 8'
( 4 ) 2” x 4” x 10'
( 15 ) 2” x 4” x 12'

2x6:
( 16 ) 2” x 6” x 8'
( 15 ) 2” x 6” x 10'
( 2 ) 2” x 6” x 12'

2x8:
( 9 ) 2” x 8” x 10'
( 1 ) 2” x 8” x 12'

4x4:
( 7 ) 4” x 4” x 8'
( 4 ) 4” x 4” x 12'

4x6:
( 2 ) 4” x 6” x 10'
( 1 ) 4” x 6” x 12'

Plywood:
( 1 ) ½" Plywood Sheets

Hardware:
(10lbs) GRK 3” R4 Screws
(15lbs) GRK 2” R4 Screws
(Optional) GRK 4” RSS Screws
(52) 5½" Carriage Bolts

Lumber List | Standard:

Decking:
( 48 ) 5/4” x 6” x 8'
( 15 ) 5/4” x 6” x 12'

2x4:
( 25 ) 2” x 4” x 8'
( 4 ) 2” x 4” x 10'
( 25 ) 2” x 4” x 12'

2x6:
( 13 ) 2” x 6” x 8'
( 10 ) 2” x 6” x 10'
( 6 ) 2” x 6” x 12'

2x8:
( 9 ) 2” x 8” x 10'
( 1 ) 2” x 8” x 12'

4x4:
( 7 ) 4” x 4” x 10'
( 1 ) 4” x 4” x 12'

4x6:
( 2 ) 4” x 6” x 10'
( 1 ) 4” x 6” x 12'

Plywood:
( 4 ) ½" Plywood Sheets
