Noah's Ark Playset Plan

$ 75.00
Credit Cards Accepted
A 3-ring binder and the PDF logo

Buy Digital & Printed Plans

You may not be able to fit two of every kind of animal on this boat, but you'll sure be able to entertain an excited group of kids who don't have to be worried about being stranded for 40 days and nights.  The 10x24 Noah's Ark playset plan is packed full of ways in and out your child will love to play on.  Six ways in and out and covering 280 square feet over two floors, these easy to follow plans will allow you to build the ultimate old school testament water vessel around.  Don't forget to also check out our Tugboat if you need something a little smaller.

Trivia:  Do you know how the animals who lived far away got to the ark?  Why, they just took the train!

Features:

  • 280 ft² in usable play space
  • 2 levels
  • 5' Wall heights
  • Trap door to 2nd floor
  • Four 2nd floor openings - Room for a slide, fire pole ship ladder & gang plank
  • Front & rear entrances on 1st floor
  • Gable Roof on 2nd floor
  • 23' long, 10.5' wide, 15' tall
  • 65 page, step by step PDF plan

Materials:

Decking:

(54) 5/4” x 6” x 8'
(78) 5/4” x 6” x 10'
(24) 5/4” x 6” x 12'
(22) 5/4” x 6” x 16'

Framing:
(35) 2” x 4” x 8'
(41) 2” x 4” x 10'
(5) 2” x 4” x 12'

(21) 2” x 6” x 8'
(20) 2” x 6” x 10'
(7) 2” x 6” x 12'

(2) 2” x 8” x 8'
( 3 ) 2” x 8” x 16'

(5) 4” x 4” x 8'

Plywood:
(3) ⅝" Plywood Sheets

Make sure to ask about and take advantage of any volume discount from your local lumber yard!

Not sure you can build this plan?
Hire a qualified professional.
